ISO4920 Textile Testing Instruments Negative Ion Tester 7.5N

Brand Name : SRI

Model Number : GB/T4745-2012

Certification : ISO 22610

Place of Origin : CHINA MAINLAND

MOQ : 1set

Price : 4000-10000

Payment Terms : L/C, D/P, D/A, T/T, Western Union, Paypal

Supply Ability : 50sets per month

Delivery Time : 5-10 working days

Packaging Details : wooden case

Sample pressure : 7.5N ± 0.2N

Test time : 1s-999min adjustable

Power supply : AC220V, 50HZ

Overall dimension : 610 * 370 * 420

Contact Now

ISO4920 Textile Negative Ion Tester Textile Testing Instruments

Application

It is used to test the amount of negative ions excited by textiles under friction.

Features

In a certain volume of test chamber, install the sample on the upper and lower friction plates and rub it under the specified conditions. Measure the number of negative ions excited in the unit volume space when the sample and the sample rub each other with an air ion measuring instrument, and record the curve of the amount of negative ions with time.

Applicable standards

GB/T4745-2012; ISO4920; AATCC22

Specifications

1. Test bin: 300mm * 560mm * 210mm
2. Ion resolution: 10/cm3
3. Ion measuring range: 10-1999 000/cm3
4. Diameter of upper friction plate: 100mm ± 0.5mm
5. Diameter of lower friction plate: 200mm ± 0.5mm
6. Offset distance of upper and lower friction disc rotation center: 50mm ± 0.5mm
7. Distance between negative ion tester test port and friction plate: 50mm ± 0.5mm
8. Sample pressure: 7.5N ± 0.2N
9. Friction speed: (60-100) rpm adjustable
10. Test time: 1s-999min adjustable
11. Power supply: AC220V, 50HZ
12. Overall dimension: 610 * 370 * 420

Standards

GB/T 4743； GB/T 6838； GB/T 14343； ISO 2060 and other relevant standards
